28ESAS110150-S-x-D15-IP
Encapsulated DC/DC PCB Mount Power Supply (DIP)
Ideal Power ESAS110150-S-x-D15 15V DC 1A Single output 15W model. Certified to UKCA, CE, RoHS, REACH & EN 62368-1/IEC 62368-1/EN 50155/EN 60601-1 Standards and complies with Efficiency Regulations. These are primarily used in ITE, Audio & Video, Railway, Medical Industries and customised solutions are available upon request.
Features
- 8:1/4:1 Wide Input Range
- Approved to UKCA, CE, RoHS & REACH
- DIP Package
- Efficiency up to 88%
- Operating Temperature Range: -40~100°C
- Safety Standards to IEC/EN 62368-1 & EN 50155
- Single output 9~160V DC
Basic Specification
| Product Type | DC/DC Converters DC/DC PCB Mount Power Supply |
|---|---|
| Input Voltage | 40~160V DC |
| Output | 15V DC 1A |
| Output Power | 15W |
| Number of Outputs | Single |
| Efficiency | 88% |
| Output Connector | Pin Connection |
| Dimensions | 32.3x16.5x10.2mm |
| Industry | ITE, Audio & Video, Railway, Medical |
| Standards | EN 62368-1, IEC 62368-1, EN 50155, EN 60601-1 |
