56YSL100D-xy SERIES

100W Triac Dimming (CV) LED Driver

Certified to UKCA, CE, CB, RCM (C-Tick), TUV-GS, cURus, RoHS, REACH & IEC 61347-1/IEC 61347-2-13 Standards and complies with Efficiency Regulations. These are primarily used in LED Lighting Industries and customised solutions are available upon request.

Features

Class II Protection Design
Constant Voltage
Input Voltage Range 100-240VAC/200-240VAC
Protection OVP, OLP, SCP
Triac Dimming
Working Temperature -20°C ~ +50°C

Basic Specification

Product Type	LED Drivers Dimmable
Input Voltage	220~240V AC 47~63Hz
Output Power	100W
Number of Outputs	Single
Input Connection	Terminal Block
Dimensions	180x66x32mm
Industry	LED Lighting
Standards	IEC 61347-1, IEC 61347-2-13

Pdf Spec Sheet

Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	56YSL100D-3601380	36V DC	1.38A	49.7W	Download Pdf
Compare	56YSL100D-4801040	48V DC	1.04A	49.9W	Download Pdf
Compare	56YSL100D-1204160	12V DC	4.16A	49.9W	Download Pdf
Compare	56YSL100D-2402080	24V DC	2.08A	49.9W	Download Pdf
